Tekniset tiedot:
Prosessorituki:
Tukee 9. ja 8. sukupolven Intel Core -prosessoreja
LGA1151
Piirisarja:
Intel B365
Muistituki:
4 x DDR4 DIMM, maks. 64GB
Dual Channel -muistiarkkitehtuuri
Tukee
DDR4 2666 / 2400 / 2133 MHz
Audio:
Realtek ALC892
Verkkokortti:
Gigabit LAN 10/100/1000 Mb/s (Giga PHY Intel I219V)
Laajennuspaikat:
2 x PCI Express 3.0 x16
2 x PCI Express 3.0 x1
1 x M.2 Socket (Key E), tukee type 2230 WiFi/BT -moduulia
Tukee AMD Quad CrossFireX ja CrossFireX
Liitännät (sisäiset):
6 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0, RAID 1, RAID 5, RAID 10, Intel® Rapid Storage Technology 17), NCQ, AHCI and Hot Plug
1 x Ultra M.2 Socket (M2_1), supports M Key type 2230/2242/2260/2280 M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4 (32 Gb/s)
1 x Ultra M.2 Socket (M2_2), supports M Key type 2230/2242/2260/2280/22110 M.2 PCI Express module up to Gen3 x4 (32 Gb/s)
1 x COM Port Header
1 x TPM Header
1 x Power LED and Speaker Header
2 x RGB LED Headers
1 x Addressable LED Header
1 x CPU Fan Connector (4-pin)
1 x CPU/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)
3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)
1 x 24 pin ATX Power Connector
1 x 8 pin 12V Power Connector
1 x Front Panel Audio Connector
1 x Thunderbolt™ AIC Connector (5-pin)
2 x USB 2.0 Headers (Support 3 USB 2.0 ports) (Supports ESD Protection)
1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection)
Liitännät (ulkoiset):
1 x PS/2 Mouse/Keyboard Port
1 x D-Sub Port
1 x DVI-D Port
1 x HDMI Port
2 x USB 2.0 Ports (Supports ESD Protection)
1 x USB 3.1 Gen1 Type-C Port (Supports ESD Protection)
5 x USB 3.1 Gen1 Ports (Supports ESD Protection)
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
HD Audio Jacks: Line in / Front Speaker / Microphone
Emolevyn tyyppi:
ATX (30,5 x 22,9 cm)
Tuetut käyttöjärjestelmät:
Microsoft Windows 10 64-bit
